Heco 5.1.2 dolby atmos home theatre system
Being a German HiFi brand,Heco is known for its quality and consistency in hifi segment.
Its 5.1.2 theatre package with main floorstanding speakers, dedicated centre channel, on wall surround channels with powerful subwoofer is as below with specific model details.
1.Heco Victa Elite 702 3-way floorstanding speakers with double bass
The good one meter high floorstanding speaker offers a true three-way system with high power handling with two 170 mm woofers, a midrange speaker of the same size and the 28 mm Fluktus tweeter. The woofers and midrange drivers have solid steel baskets and 8-fold screwed decorative rings. The woofer duo confidently reproduces frequencies down to 25 Hz. At the other end of the frequency scale, the tweeter makes music up to 40,000 Hz.Whether in black or white, the 702 is both imposing and elegant. The massive cabinet with its internal bracing provides the best working conditions for the drivers. Height-adjustable metal spikes or alternatively rubber spikes guarantee a secure stand and avoid resonances. Thanks to the optimized bass reflex design, the Victa Elite 702 masters even the highest levels without flow noise. Whether as a soloist in a demanding stereo setup or as the main speaker of a surround system, the 702 is the perfect choice in any case.
Sensitivity (2.8V/1M) -91db
Impedance- 4-8 ohms
Power Handling (RMS/MAX) – 170-300
Dimensions (WXHXD) -202x1050x310mm
Crossover-
- Elaborated phase and amplitude optimized crossover with high-quality components
- High-quality connecting terminal with solid, gold-plated and capsulated screw connectors
- Bi-wiring/Bi-amping-Option
Tweeter with 28 mm silk compound dome, ferrofluid cooling for high capacity, powerful ferrite double magnet system and new Fluctus acoustic flange geometry
Mid-bass driver specially optimised for low-distortion reproduction with lightweight long-fibre cone, inverse dust dome of the same material, long-throw surround and heavy-duty voice coil.
2.Heco Victa Elite 102 bass reflex 2-way Center speaker
- Two 120 mm woofers with long-fiber cone and solid steel basket
- 28 mm Fluktus tweeter with new acoustic flange geometry
- High-quality connection terminal with encapsulated, gold-plated screw terminals
- Includes rubber spikes for acoustical decouplin
No home theater is complete without a powerful center speaker, because it often has the most work to do, especially during action scenes. The Victa Elite 102 center is the ideal sparring partner for this job. No less than two 120 mm woofers and of course the Fluktus tweeter with its 28 mm dome made of a silk composite material. Thanks to ferrofluid cooling, this is extremely resilient and thus ideally equipped for its task. The bass-midrange drivers can boast solid steel baskets and are screwed 6-fold with their decorative rings. The result is a frequency response of 35 to 40,000 Hz and impressive dynamics. The center is also available in black and white and is therefore the ideal addition to any Victa Elite system that is to be expanded into a surround system. And this applies not only to movie sound, but also to the increasingly popular music playback in multi-channel sound. Weighing in at 6.4 kg, it’s immediately apparent how much high-quality technology is packed into the center despite its compact dimensions. With a width of 48 cm, a height of 16 and a depth of 26 cm, the Victa Elite Center 102 cuts an excellent figure in conjunction with any TV set, but also a projection.
Sensitivity (2.8V/1M) -90db
Impedance- 4-8 ohms
Power Handling (RMS/MAX) – 170-300
Dimensions (WXHXD) -202x1050x310mm
3.Heco Ambient 22F universal wall mounted speakers
- 28 mm tweeter dome with Fluktus technology
- Two 125 mm bass-midrange drivers with kraft paper cones
- Integrated metal wall brackets for horizontal and vertical installation
- Preparation for VESA brackets with a hole spacing of 100 mm
- Finish: Silk-matt black and silk-matt white finish
- 3 different covering frames
Sensitivity (2.8V/1M) -88db
Impedance- 4-8 ohms
Power Handling (RMS/MAX) – 70-120
Dimensions (WXHXD) -225x445x85mm
Frequency response- 50-42500hz
4.Heco INC82 Ceiling speakers for dolby atmos
Its nominal diameter of 200 mm enables a powerful reproduction of the bass range and a high maximum volume. The waterproof textured polypropylene cone and the specially coated fabric dome tweeter deliver a fully-fledged sound pattern in conjunction with a high quality 2-way crossover. Its coaxial driver configuration makes it particularly suitable for ceiling installation. The pivoting tweeter and level adjustment option mean the acoustics can also be ideally adapted to the respective installation conditions. The grille, which can be removed for installation purposes, provides a seamless transition to the discreet mounting frame.
Driver size-1″ dome tweeter and 6.5″woofer
Sensitivity (2.8V/1M) -90db
Impedance- 4 ohms
Power Handling (RMS/MAX) – 80-150watt
Outer dimension-228mm
Mounting dimensions-193mm
Cutout dimensions-73mm
Frequency response- 36-28000hz
5.Heco Victa Elite 252A active subwoofer
The Victa Elite Sub 252A active subwoofer with its high-power long-throw woofer ensures an emphatic acoustic experience down to 22 Hz. It is supported by a powerful Class AB power amplifier with 100 watts continuous and 200 watts peak power, which is perfectly matched to the woofer. For optimal matching to the rest of the speaker system, volume and crossover frequency can be adjusted, the latter between 50 and 150 Hz, depending on which main speakers are used. Phase is also switchable to allow the Victa Elite Sub 252 A to resonate in time with the rest of the system. An active frequency response equalization guarantees that the chassis delivers optimal results. However, only the subwoofer should vibrate and not the cabinet. Therefore, this consists of solid MDF and is elaborately braced inside, which manifests itself in a weight of almost 16 kg. Visually, the active speaker fits perfectly with the other speakers in the series, as it also has rounded side panels and is available in both black and white.
Driver size-10″
Power output-100-200watt
Frequency response-22-150hz
Crossover frequency-50-150hz
Dimensions-322x458x405mm
As mentioned above models and consideration of specification matching processor and amplifier can select and can enjoy home theatre experience. Better processor can lead to awesome experience.
